200T Pressure High Automatic Perforating Machine for Max 20mm Thickness Gypsum Board Punching

200T Pressure High Automatic Perforating Machine for Max 20mm Thickness Gypsum Board Punching

Marka Adı:	LVJOE
Model Numarası:	LV-CK01
Moq:	1 Takım
fiyat:	US $20000-80000
Tedarik Yeteneği:	Yılda 50 set

Ayrıntılı Bilgiler

Ürün Tanımı

Ayrıntılı Bilgiler

Menşe yeri:

Çin

Sertifika:

ISO CE

Ürün Adı:

Ses Yalıtım Levhası Delme Ekipmanları Yüksek Hızlı Alçıpan Delme Makinesi

Anahtar kelime:

Sürekli Üretim Alçıpan Delici

Basınç:

80T, 160T, 200t

Kullanım:

Alçıtma tahtası, MDF, HPL, Fiber Çimento Kartı Perforasyonu

Delikler:

Yuvarlak, kare

Otomatik Seviye:

Yüksek Otomatik

Kalınlık:

Maks. 20 mm

Garanti:

1 Yıl

Başvuru:

İç Tavan ve Bölme

Özellik:

YAYGIN

Ambalaj bilgileri:

PE Film sarılmış

Yetenek temini:

Yılda 50 set

Ürün Tanımı

Sound Insulation Board Perforating Equipment High Speed Plaster Board Punch Machine

High-performance gypsum board drilling equipment designed for precision perforation in various building materials.

Product Specifications

Pressure	80T, 160T, 200T
Usage	Gypsum Board, MDF, HPL, Fiber cement board perforation
Holes	Round, Square
Automatic Level	High automatic
Thickness	Max. 20mm

Technical Specifications

Punching pressure: 200 ton
Stroke: 30 mm
Max mold height closed: 260mm
Number of strokes: 50 times/minute
Slide surface: 210*1100mm
Working table: 300*1670mm
Spacing of both pole: 1350mm (load the max board width 1220mm)
Power of main motor: 22kw
Power of servo motor: 2.6kw (brand: Zhejiang yifeng)
Feeding accuracy: ±1mm
Maximum feeding rate: 100mm
Maximum feeding thickness: 20mm
Gross weight of machine: 11000kg
Overall dimension: 2300*1500*2300(H*L*W)

Applications

This perforation machine is designed for creating holes in various materials including gypsum ceiling board, MgO board, MDF, HPL, Fiber cement board, and metal sheets. Custom hole shapes are available to meet specific requirements. Comprehensive operational training is provided.
