Fully Automatic High Capacity Variable Speed PU Sandwich Panel Making Machine for Prefab House Production Line

Fully Automatic High Capacity Variable Speed PU Sandwich Panel Making Machine for Prefab House Production Line

Marka Adı:	Greenson
Moq:	1
fiyat:	$790000
Ödeme Şartları:	L/C,T/T

Ayrıntılı Bilgiler

Ürün Tanımı

Ayrıntılı Bilgiler

Menşe yeri:

Hebei

Ürün adı:

Prefabrik Ev İçin Otomatik PU Sandviç Panel Yapma Makinesi Üretim Hattı

Anahtar kelime:

Poliüretan Köpük Sandviç Seksiyonel Garaj Kapısı Panel Makinası Üretim Hattı

Renk:

Müşterinin Gereksinimi

Özellik:

Tam Otomatik

Ambalaj bilgileri:

Plastik Film

Sevkiyat limanı:

TianJin

çekirdek bileşenler:

PLC, Motor, Rulman, Motor, Pompa

önemli satış noktaları:

Kullanımı Kolay

Başvuru:

Çatı ve Duvar

Gerilim:

380V 50Hz 3 faz (ihtiyaca göre değiştirilebilir)

Ürün Tanımı

Automatic PU Sandwich Panel Making Machine Production Line For Prefab House

Product Overview

This advanced production line features a rational structure, complete functionality, and easy operation. Designed for manufacturing high-quality rock wool sandwich panels through a fully automated continuous process.

Fully Automatic: Effortlessly produces high-quality sandwich panels
High Capacity: Handles large-scale production with efficiency
Variable Speed: Adjusts to match production needs for optimal output
Multiple Material Options: Suitable for color steel sheets, galvanized sheets, and aluminum sheets
Guaranteed Quality: Equipped with video factory inspection and mechanical test reports

Production Process

Complete automated workflow: feeding, profiling, gluing, heating, trimming, grooving, and cutting
Precision low-speed metering pump with computer-controlled frequency regulation
Accurate dosing and stepless speed adjustment capabilities

Product Capabilities

Produces various flat and corrugated sheet types
Sandwich panels: thickness 40-300 mm, width 950-1200 mm
High-strength corrugated composite boards: thickness 40-300 mm, width 950-980 mm
Compatible with color steel plates, aluminum plates, stainless steel plates, and other sheet materials

Technical Specifications

Material Type	Color steel sheet; Galvanized sheet; Aluminum sheet
Material Thickness	0.3-0.8 mm
Material Width	≤1250 Mpa
Suitable Panel Length	2000-18000 mm
Suitable Panel Width	500-1200 mm
Suitable Panel Thickness	30-250 mm (excluding corrugation height)
Production Speed	3-15 m/min (Adjustable)
Valid Length of Double Belt Conveyor	12000-42000 mm
Work Pressure on Pouring Foam	150-200 Bar
Total Power	660 kW / 300 kW
Total Dimensions	130000 × 15000 × 6000 mm (Length × Width × Height)
