PLC System Controlled PVC Laminated Gypsum Board Machine with 1300mm Laminating Width and 15m/min Speed

PLC System Controlled PVC Laminated Gypsum Board Machine with 1300mm Laminating Width and 15m/min Speed

Marka Adı:	LVJOE
Model Numarası:	1300FM01
Moq:	1 TAKIM
fiyat:	US $20000-200000
Ödeme Şartları:	L/C,T/T
Tedarik Yeteneği:	Yılda 50 set

Ayrıntılı Bilgiler

Ürün Tanımı

Ayrıntılı Bilgiler

Menşe yeri:

Hebei, Çin (Anakara)

Sertifika:

CE ISO 9001

Ürün Adı:

Levha Kesme Makinası ve Termoplastik Paketleme Makinası Pano PVC Lamine Alçıpan Tavan Fayansları

Anahtar kelime:

Alçıpan fayans makinesi

Gerilim:

380V

Garanti:

1 Yıl

Boyut(U*G*Y):

12600*1950*1600

Tahrikli tip:

PLC Sistemi

Ağırlık:

3-30T

Özellikler:

Kullanımı Kolay

Ambalaj bilgileri:

İhracat için standart paket veya PVC ve Pet Film Talep'e göre, alçı tavan panosu yapma makineler

Yetenek temini:

Yılda 50 set

Vurgulamak:

PLC System Gypsum Ceiling Tile Production Line

1300mm Laminating Width PVC Laminated Gypsum Board Machine

15m/min Laminating Speed Board Cutting Machine

Ürün Tanımı

Board Cutting Machine & Thermoplastic Packing Machine for PVC Laminated Gypsum Board Ceiling Tiles

This fully automatic cutting machine is engineered for PVC laminated gypsum board ceiling tile production, efficiently processing surface decorative materials including films, papers, and laminates for various board types.

Technical Specifications

Attribute	Value
Voltage	380V
Warranty	1 Year
Dimension (LWH)	1260019501600 mm
Driven Type	PLC System
Weight	3-30t
Features	Easy To Operate

Machine Capabilities

Parameter	Specification
Effective Laminating Width	≤1300mm
Sheet Thickness	5-30mm
Laminating Speed	15m/min
Speed Adjustment	Frequency conversion synchronous speed regulating
Electrical Control	PLC system
Film Material	PVC film, aluminum foils, decorative material
Installed Power	4kw

Standard Gypsum Ceiling Tile Sizes

595*595*8.0mm
603*603*8.0mm
600*1200*8.0mm

Operation Process

The machine precisely cuts laminated gypsum boards to required sizes according to saw gauge standards. Boards are placed on delivery rolls, processed through the cutting system twice for enhanced accuracy, and delivered as finished products. The system can be optionally equipped with a pulsed sack-duster.

Our Manufacturing Advantages

Competitive Pricing

Direct factory production with 15+ years of specialization in PVC laminated gypsum ceiling tile machinery

Superior Quality

Rigorous quality control standards throughout manufacturing

Comprehensive Service

Specialized international trading company focused on export business

Complete After-sales Support

Engineers provide production line design, installation, commissioning, and operator training
